223.6 m · net rise 45.7 m · overall 20.4% · evidence quality B (good) · Los Angeles · California
Shape: sustained — 40% of the climbing sits in a quarter of the distance; longest continuous stretch at 10%+ is 128 m.
Not yet matched against documented climbs — the measurement stands on its own.
Gradient ladder what do windows mean?
| Window | Maximum | Located at | |
|---|---|---|---|
| 2 m (diagnostic) | 35% | 211–213 m | |
| 3 m (diagnostic) | 35% | 211–214 m | |
| 5 m | 34% | 211–216 m | |
| 10 m | 34% | 211–221 m | |
| 20 m | 33.1% | 203–223 m | |
| 25 m | 33.1% | 198–223 m | |
| 50 m | 32.7% | 173–223 m | |
| 100 m | ≈30.6% | 123–223 m | under overhead cover |
may continue beyond end Extent detection suggests reviewing where this climb starts/ends.
Map
Check this route yourself: Google Maps route via their router · Street View at the base where coverage exists · geojson.io our exact measured line · OpenTopoMap
This climb's data: OCL JSON — the full gradient ladder, quality flags and provenance in the OpenClimb Ladder format.
Surface: each state's road inventory records no surface for this road; the map may tell you more.
Access: Listed unranked 2026-09-30: route doctor leading_descent — the line started with a 14 m descent (30 % of the rise) before the climb. TRIMMED + RE-MEASURED 2026-09-30 (base_cut_m: 161 to the published profile's own low point + the already-present summit_trim: true, on box 5.78.138.250, main fbc59ed4): 384.6 m -> 223.6 m, overall 8.31 % -> 20.44 %, steepest 25 m unchanged 33.12 % (window sits entirely past the cut). Route doctor 0 failing on the trimmed line. Ranked (Peter, 2026-08-27: never silently ranked or dropped — this lift is the trim landing, not a silent one).
Measured, not vetted. This page records what the laser record shows about the road's shape — nothing more. Nobody has necessarily ridden or inspected this road for the survey, and a page here is not a recommendation and no guarantee that the road is open, surfaced, rideable or safe. Gates, private sections, missing rights of way and hazards do not show up in elevation data. Check access and conditions on the ground and make your own judgment.
Ridden it, or know better? Submit data for this climb no account needed · Share this climb
Route colour = gradient over a 25 m window: <10% 10–20% 20–25% ≥25%
Route line = the road surface as the LiDAR survey finds it. Basemap roads are for orientation and may sit a few metres off.
© OpenStreetMap contributors · topo tiles © OpenTopoMap (CC-BY-SA) · vector tiles OpenFreeMap · aerial imagery USGS (public domain)
Profile
The map, profile and gradient chart share one position — move your pointer over them and the marker follows. Colors are the gradient bands; the shaded span is the steepest 25 m. Any 25 m figure is good to about a point either way (why).
Measurement card
| Elevation | USGS 3DEP (The National Map) — USGS 3DEP 1 m DEM, CA_LosAngeles_B23 (collected 2023-24) |
|---|---|
| Resolution / CRS | 1.0 m grid, EPSG:26911; sampled every 1.0 m, bilinear interpolation |
| Tiles | x38y378 |
| Road centreline | OpenStreetMap (local PBF extract) |
| Quality status | evidence quality B; caveated windows: canopy or structure |
| Analysis | OCL 0.1.0, analysis 0.1.0, run eldred-trim-260930, calculated 2026-09-30 |
Provenance
{
"analysis_version": "0.1.0",
"run_manifest": {
"manifest_version": "1",
"code_git_sha": "fbc59ed4c53a24e31d1cb1525a76ed4e7e597766",
"code_git_dirty": "false",
"analysis_version": "0.1.0",
"analysis_config_digest": "sha256:8c94015b54267da4",
"python": "3.14.4",
"numpy": "2.5.3",
"rasterio": "1.5.1",
"pyproj": "3.8.0",
"laspy": "2.7.0",
"shapely": "2.1.2",
"pyosmium": "4.3.1",
"libosmium": "2.23.1",
"gdal": "3.12.4",
"proj": "9.8.1",
"run_id": "eldred-trim-260930",
"road_pbf": "block.osm.pbf",
"region_key": "usa-ca-east",
"crs": "EPSG:26911",
"elevation_provider_key": "usa3dep",
"authority": "usa-inventory",
"registry_pbf": "california-2026-09-29.osm.pbf",
"tile_index_snapshot": "sha256:c98325348ae2ec01"
},
"sample_interval_m": 1.0,
"interpolation": "bilinear",
"smoothing": "none",
"gradient_windows_m": [
5.0,
10.0,
20.0,
25.0,
50.0,
100.0
],
"diagnostic_windows_m": [
2.0,
3.0
],
"elevation_crs": "EPSG:26911",
"elevation_resolution_m": 1.0,
"elevation_tiles": [
"/root/uk-climbs/data/cache/usa/ca-east/USGS_1M_11_x38y378_CA_LosAngeles_B23.tif"
],
"calculated_at": "2026-09-30T04:03:39+00:00",
"road_source": "OpenStreetMap (local PBF extract)",
"road_attribution": "\u00a9 OpenStreetMap contributors, ODbL",
"osm_pbf_path": "/root/uk-climbs/output/us-west-la-hills/block.osm.pbf",
"osm_snapshot": "",
"run_id": "eldred-trim-260930",
"elevation_provider": "USGS 3DEP (The National Map)",
"elevation_licence": "Public domain \u2014 USGS 3DEP 1 m DEM, courtesy of the U.S. Geological Survey",
"elevation_dataset": "USGS 3DEP 1 m DEM, CA_LosAngeles_B23 (collected 2023-24)",
"elevation_tile_ids": [
"x38y378"
],
"route_base_cut_m": 161,
"climb_origin": "named-pass",
"named_pass": "Eldred Street",
"any_length": true,
"seam_filled_samples": {
"count": 0,
"distances_m": []
},
"seam_filled_in_maximum": false,
"canopy_source": {
"kind": "ept_corridor_max_return",
"ept_source": "https://s3-us-west-2.amazonaws.com/usgs-lidar-public/CA_LosAngeles_1_B23",
"ept_crs": "EPSG:3857",
"station_coverage": 1.0,
"cell_ground_m": 1.0,
"nodes_failed": 0,
"window_coverage": {
"5": 1.0,
"10": 1.0,
"20": 1.0,
"25": 1.0
}
},
"structure_own_ways": 1,
"structure_own_ways_source": "map-matched to the road network: the entry carried no way list, so the ways the route runs along were found by geometry (ukclimb.batch.own_ways_by_geometry)",
"carriageway": {
"stations": 15,
"stations_resolved": 15,
"width_median_m": 5.25,
"width_p10_m": 4.35,
"width_min_m": 3.75,
"width_max_m": 10.0,
"bounded_share": 0.0,
"unbounded_share": 1.0,
"confidence_median": 0.0,
"window_m": [
198.0,
223.0
],
"width_at_max25_m": 4.75,
"window_stations": 7,
"single_track": false,
"single_track_rule": "PROVISIONAL (2026-09-15): width_p10_m <= 3.0 m with bounded_share >= 0.6; recorded, not a rule",
"status": "ok",
"source": "dtm",
"station_m": 25.0,
"window_station_m": 5.0,
"halfwidth_m": 6.0,
"step_m": 0.25,
"level_tol_m": 0.12,
"break_min_m": 0.3,
"stations_failed": 0,
"hedge_to_hedge": {
"status": "unavailable \u2014 no DSM raster (surface model absent or point-cloud only, which cannot serve off-line samples)"
}
},
"license": "ODbL-1.0",
"license_url": "https://howsteep.org/licensing"
}
