2716.0 m · net rise 105.7 m · total ascent 191.8 m · overall 3.9% · evidence quality B (good) · Heim · Trøndelag
Shape: sustained — 32% of the climbing sits in a quarter of the distance; longest continuous stretch at 10%+ is 83 m.
Found purely from mapping and LiDAR data, and not yet matched against books, race records or lists — it may be well known to locals under a name we've never heard. It was cross-checked against the NVDB road network, OpenStreetMap and a second terrain model, but a discovery can still be an artifact of the terrain model or the map. Treat it as a well-evidenced hypothesis until someone has ridden it. If you know this road, tell us what you found — photographs, corrections and local knowledge all welcome; the map links below let you scout it first.
≈ Overhead cover (tree canopy or structures) spans 34% of this route — detected by comparing the surface model (DSM, treetops and rooftops) against the terrain model (DTM, bare ground). Under cover the bare-ground model is built from fewer laser returns, so metre-scale readings can wobble; maxima whose window sits in a covered zone are marked ≈ below — less certain — the flag does not say whether the true value is higher or lower. Longer windows average over more clean ground and are steadier.
Gradient ladder what do windows mean?
| Window | Maximum | Located at | |
|---|---|---|---|
| 2 m (diagnostic) | ≈55% | 2654–2656 m | under overhead cover terrain reads 106.5% at 1589–1591 m across a structure — excluded |
| 3 m (diagnostic) | ≈50% | 2426–2429 m | under overhead cover terrain reads 89.9% at 1589–1592 m across a structure — excluded |
| 5 m | ≈41% | 2599–2604 m | under overhead cover terrain reads 81.2% at 1589–1594 m across a structure — excluded |
| 10 m | ≈34% | 2647–2657 m | under overhead cover terrain reads 49.2% at 2226–2236 m across a structure — excluded |
| 20 m | ≈32.3% | 2637–2657 m | under overhead cover terrain reads 38.9% at 1232–1252 m across a structure — excluded |
| 25 m | ≈29.0% | 2639–2664 m | under overhead cover terrain reads 35.6% at 1230–1255 m across a structure — excluded |
| 50 m | 25.7% | 2607–2657 m | |
| 100 m | ≈22.0% | 2596–2696 m | under overhead cover terrain reads 23.8% at 2565–2665 m across a structure — excluded |
may start earliermay continue beyond end Extent detection suggests reviewing where this climb starts/ends.
Map
Check this route yourself: Google Maps route via their router · Street View at the base where coverage exists · geojson.io our exact measured line · OpenTopoMap
This climb's data: OCL JSON — the full gradient ladder, quality flags and provenance in the OpenClimb Ladder format.
Surface: paved (0% unpaved), according to NVDB, Norway's National Road Database: surface unrecorded for the first 99 m; paved from 99 m to the top.
Access: Ranked 2026-10-05 (D27, road authority): NVDB carries 100% of the route as public road (4% restricted), which answers the OSM audit question (unnamed service way, untagged surface).
Measured, not vetted. This page records what the laser record shows about the road's shape — nothing more. Nobody has necessarily ridden or inspected this road for the survey, and a page here is not a recommendation and no guarantee that the road is open, surfaced, rideable or safe. Gates, private sections, missing rights of way and hazards do not show up in elevation data. Check access and conditions on the ground and make your own judgment.
Ridden it, or know better? Submit data for this climb no account needed · Share this climb
Route colour = gradient over a 25 m window: <10% 10–20% 20–25% ≥25%
Route line = the road surface as the LiDAR survey finds it. Basemap roads are for orientation and may sit a few metres off.
© OpenStreetMap contributors · topo tiles © OpenTopoMap (CC-BY-SA) · vector tiles OpenFreeMap
Profile
The map, profile and gradient chart share one position — move your pointer over them and the marker follows. Colors are the gradient bands; the shaded span is the steepest 25 m. Any 25 m figure is good to about a point either way (why).
Measurement card
| Elevation | Kartverket NHM DTM 1 m (laser-covered ground only) — Nasjonal høydemodell (NHM) DTM, 1 m, EPSG:25833, NN2000 (Kartverket), served by the hoydedata.no ImageServer; ground without a laser project is a coarser resampled product and is never measured |
|---|---|
| Resolution / CRS | 1.0 m grid, EPSG:25833; sampled every 1.0 m, bilinear interpolation |
| Tiles | E176000-N7018000, E176000-N7018500, E176000-N7019000, E176000-N7019500, E176000-N7020000, E176500-N7018000, E176500-N7018500, E176500-N7019000, E176500-N7019500, E176500-N7020000, E177000-N7019500, E177000-N7020000, E177500-N7020000, E178000-N7020000, E178500-N7020000 |
| Road centreline | OpenStreetMap (local PBF extract) |
| Quality status | evidence quality B; caveated windows: canopy or structure, structure excluded, structure excluded min, suppression unstable, texture excluded |
| Analysis | OCL 0.1.0, analysis 0.1.0, run no-b09, calculated 2026-10-04 |
Provenance
{
"analysis_version": "0.1.0",
"run_manifest": {
"manifest_version": "1",
"code_git_sha": "368c60c29e47d4b421849c953b172a04f7694146",
"code_git_dirty": "false",
"analysis_version": "0.1.0",
"analysis_config_digest": "sha256:8c94015b54267da4",
"python": "3.14.4",
"numpy": "2.5.3",
"rasterio": "1.5.2",
"pyproj": "3.8.0",
"laspy": "2.7.0",
"shapely": "2.1.2",
"pyosmium": "4.3.1",
"libosmium": "2.23.1",
"gdal": "3.12.2",
"proj": "9.8.1",
"run_id": "no-b09",
"road_pbf": "no-b09-block-batch-no-b09.osm.pbf",
"region_key": "norway",
"crs": "EPSG:25833",
"elevation_provider_key": "nhm-no",
"tile_index": "nhm-window",
"authority": "nvdb",
"registry_pbf": "norway-2026-10-01.osm.pbf"
},
"sample_interval_m": 1.0,
"interpolation": "bilinear",
"smoothing": "none",
"gradient_windows_m": [
5.0,
10.0,
20.0,
25.0,
50.0,
100.0
],
"diagnostic_windows_m": [
2.0,
3.0
],
"scale_correction": "point",
"scale_correction_crs": "EPSG:25833",
"elevation_crs": "EPSG:25833",
"elevation_resolution_m": 1.0,
"elevation_tiles": [
"data/cache/no/nhm-no_dtm_E176000-N7018000_1m.tif",
"data/cache/no/nhm-no_dtm_E176000-N7018500_1m.tif",
"data/cache/no/nhm-no_dtm_E176000-N7019000_1m.tif",
"data/cache/no/nhm-no_dtm_E176000-N7019500_1m.tif",
"data/cache/no/nhm-no_dtm_E176000-N7020000_1m.tif",
"data/cache/no/nhm-no_dtm_E176500-N7018000_1m.tif",
"data/cache/no/nhm-no_dtm_E176500-N7018500_1m.tif",
"data/cache/no/nhm-no_dtm_E176500-N7019000_1m.tif",
"data/cache/no/nhm-no_dtm_E176500-N7019500_1m.tif",
"data/cache/no/nhm-no_dtm_E176500-N7020000_1m.tif",
"data/cache/no/nhm-no_dtm_E177000-N7019500_1m.tif",
"data/cache/no/nhm-no_dtm_E177000-N7020000_1m.tif",
"data/cache/no/nhm-no_dtm_E177500-N7020000_1m.tif",
"data/cache/no/nhm-no_dtm_E178000-N7020000_1m.tif",
"data/cache/no/nhm-no_dtm_E178500-N7020000_1m.tif"
],
"calculated_at": "2026-10-04T03:34:27+00:00",
"road_source": "OpenStreetMap (local PBF extract)",
"road_attribution": "\u00a9 OpenStreetMap contributors, ODbL",
"osm_pbf_path": "data/cache/pbf/no-b09-block-batch-no-b09.osm.pbf",
"osm_snapshot": "",
"run_id": "no-b09",
"elevation_provider": "Kartverket NHM DTM 1 m (laser-covered ground only)",
"elevation_licence": "CC BY 4.0 \u2014 \u00a9 Kartverket (https://www.kartverket.no/api-og-data/vilkar-for-bruk)",
"elevation_dataset": "Nasjonal h\u00f8ydemodell (NHM) DTM, 1 m, EPSG:25833, NN2000 (Kartverket), served by the hoydedata.no ImageServer; ground without a laser project is a coarser resampled product and is never measured",
"elevation_vertical_datum": "NN2000",
"elevation_tile_ids": [
"E176000-N7018000",
"E176000-N7018500",
"E176000-N7019000",
"E176000-N7019500",
"E176000-N7020000",
"E176500-N7018000",
"E176500-N7018500",
"E176500-N7019000",
"E176500-N7019500",
"E176500-N7020000",
"E177000-N7019500",
"E177000-N7020000",
"E177500-N7020000",
"E178000-N7020000",
"E178500-N7020000"
],
"elevation_blocks": [
"nhm-dtm-1m"
],
"nhm_laser_projects": [
{
"last_flight_date": "2012-06-07",
"name": "E39 Leirvika-Stokkj\u00f8len 2012",
"points_per_m2": 5,
"resolution_m": 0.25,
"season": "",
"year": 2012
},
{
"last_flight_date": "2015-06-27",
"name": "Haram Skodje \u00d8rskog Vestnes 10pkt 2015",
"points_per_m2": 10,
"resolution_m": 0.25,
"season": "",
"year": 2015
},
{
"last_flight_date": "2016-10-04",
"name": "NDH Halsa-Tingvoll 2pkt 2016",
"points_per_m2": 2,
"resolution_m": 0.5,
"season": "",
"year": 2016
},
{
"last_flight_date": "2016-10-16",
"name": "NDH Surnadal-Rindal 2pkt 2016",
"points_per_m2": 2,
"resolution_m": 0.5,
"season": "",
"year": 2016
},
{
"last_flight_date": "2014-01-01",
"name": "Tr\u00f8ndelag del1 3pkt 2014",
"points_per_m2": 1,
"resolution_m": 1,
"season": "season-unknown",
"year": 2014
}
],
"nhm_last_flight_date": "2016-10-16",
"nhm_flight_season_unknown": [
"Tr\u00f8ndelag del1 3pkt 2014"
],
"nhm_retrieved_at": "2026-10-03T23:36:28Z",
"nhm_note": "laser projects overlapping the route's cells; the mosaic draws on them by its own priority and which project supplied which pixel is not recorded",
"route_summit_trim_m": 1148.2,
"route_summit_trim_loss_m": 52.3,
"climb_origin": "discovered",
"seam_filled_samples": {
"count": 0,
"distances_m": []
},
"seam_filled_in_maximum": false,
"structure_own_ways": 3,
"tunnel_check": "osm tunnel=* ways on 3 own way(s)",
"tunnel_ranges_m": [],
"underground_fraction": 0.0,
"suppression_unstable": [
5.0
],
"carriageway": {
"stations": 115,
"stations_resolved": 115,
"width_median_m": 5.75,
"width_p10_m": 2.75,
"width_min_m": 0.5,
"width_max_m": 12.0,
"bounded_share": 0.157,
"unbounded_share": 0.843,
"confidence_median": 0.0,
"width_median_bounded_m": 3.25,
"window_m": [
2639.0,
2664.0
],
"width_at_max25_m": 6.0,
"window_stations": 7,
"single_track": false,
"single_track_rule": "PROVISIONAL (2026-09-15): width_p10_m <= 3.0 m with bounded_share >= 0.6; recorded, not a rule",
"status": "ok",
"source": "dtm",
"station_m": 25.0,
"window_station_m": 5.0,
"halfwidth_m": 6.0,
"step_m": 0.25,
"level_tol_m": 0.12,
"break_min_m": 0.3,
"stations_failed": 0,
"hedge_to_hedge": {
"stations": 115,
"stations_resolved": 115,
"width_median_m": 4.25,
"width_p10_m": 1.25,
"width_min_m": 0.5,
"width_max_m": 12.0,
"bounded_share": 0.704,
"unbounded_share": 0.296,
"confidence_median": 1.0,
"width_median_bounded_m": 2.75,
"window_m": [
2639.0,
2664.0
],
"width_at_max25_m": 5.5,
"window_stations": 7,
"status": "ok",
"source": "dsm",
"station_m": 25.0,
"window_station_m": 5.0,
"halfwidth_m": 6.0,
"step_m": 0.25,
"level_tol_m": 0.5,
"break_min_m": 0.3,
"stations_failed": 0
}
},
"license": "ODbL-1.0",
"license_url": "https://howsteep.org/licensing"
}
