Adelbauerweg

1344.6 m · net rise 149.0 m · overall 11.1% · evidence quality B (good) · Eibiswald · Steiermark · share

Shape: sustained — 29% of the climbing sits in a quarter of the distance; longest continuous stretch at 10%+ is 272 m.

Found purely from mapping and LiDAR data, and not yet matched against books, race records or lists — it may be well known to locals under a name we've never heard. It was cross-checked against the GIP.at road network, OpenStreetMap and a second terrain model, but a discovery can still be an artifact of the terrain model or the map. Treat it as a well-evidenced hypothesis until someone has ridden it. If you know this road, tell us what you found — photographs, corrections and local knowledge all welcome; the map links below let you scout it first.

≈ Overhead cover (tree canopy or structures) spans 43% of this route — detected by comparing the surface model (DSM, treetops and rooftops) against the terrain model (DTM, bare ground). Under cover the bare-ground model is built from fewer laser returns, so metre-scale readings can wobble; maxima whose window sits in a covered zone are marked ≈ below — less certain — the flag does not say whether the true value is higher or lower. Longer windows average over more clean ground and are steadier.

Gradient ladder what do windows mean?

Window	Maximum	Located at
2 m (diagnostic)	24%	1319–1321 m
3 m (diagnostic)	24%	1319–1322 m
5 m	23%	1318–1323 m
10 m	≈22%	1318–1328 m	under overhead cover
20 m	≈20.7%	1318–1338 m	under overhead cover
25 m	20.5%	1312–1337 m
50 m	15.3%	1162–1212 m
100 m	14.9%	1125–1225 m

may start earliermay continue beyond end Extent detection suggests reviewing where this climb starts/ends.

Map

Check this route yourself: Google Maps route via their router · Street View at the base where coverage exists · geojson.io our exact measured line · OpenTopoMap

This climb's data: OCL JSON — the full gradient ladder, quality flags and provenance in the OpenClimb Ladder format.

Surface: GIP.at, Austria's official transport graph records no surface for this road; the map may tell you more.

Access: Held 2026-09-13 (hairpin cut, window off the road): the steepest window sits 17 m off the road authority's centreline, and the line bends 125 degrees within 60 m of the window with a 60-degree kink inside it — the measured line has cut the inside of a switchback and read the bank, not the road (Llanellen to Coed y Prior class, Peter 2026-09-13; the standing rule of 2026-09-09 holds any window more than 15 m off the inventory line). Out of the rankings until the line is re-drawn round the bend and re-measured; the profile is shown as measured. Peter 2026-09-15 (aerial): "redraw is worse" — the attempted redraw is rejected, the published line stands and the page stays listed.

Measured, not vetted. This page records what the laser record shows about the road's shape — nothing more. Nobody has necessarily ridden or inspected this road for the survey, and a page here is not a recommendation and no guarantee that the road is open, surfaced, rideable or safe. Gates, private sections, missing rights of way and hazards do not show up in elevation data. Check access and conditions on the ground and make your own judgment.

Ridden it, or know better? Submit data for this climb no account needed · Share this climb

Route colour = gradient over a 25 m window: <10% 10–20% 20–25% ≥25%

Adelbauerweg LiDAR hillshade map with contours

Profile

The map, profile and gradient chart share one position — move your pointer over them and the marker follows. Colors are the gradient bands; the shaded span is the steepest 25 m. Any 25 m figure is good to about a point either way (why).

Measurement card

Elevation	BEV ALS DTM 1 m — ALS DTM Höhenraster 1 m (Bundesamt für Eich- und Vermessungswesen with the Länder), EPSG:3035
Resolution / CRS	1.0 m grid, EPSG:3035; sampled every 1.0 m, bilinear interpolation
Tiles	E4725-N2629, E4725-N2630
Road centreline	OpenStreetMap (local PBF extract)
Quality status	evidence quality B; caveated windows: canopy or structure
Analysis	OCL 0.1.0, analysis 0.1.0, run at-run4-260912, calculated 2026-09-13

Provenance

{
  "analysis_version": "0.1.0",
  "sample_interval_m": 1.0,
  "interpolation": "bilinear",
  "smoothing": "none",
  "gradient_windows_m": [
    5.0,
    10.0,
    20.0,
    25.0,
    50.0,
    100.0
  ],
  "diagnostic_windows_m": [
    2.0,
    3.0
  ],
  "elevation_crs": "EPSG:3035",
  "elevation_resolution_m": 1.0,
  "elevation_tiles": [
    "data/cache/at/bev-als_dtm_E4725-N2629.tif",
    "data/cache/at/bev-als_dtm_E4725-N2630.tif"
  ],
  "calculated_at": "2026-09-13T00:20:32+00:00",
  "road_source": "OpenStreetMap (local PBF extract)",
  "road_attribution": "\u00a9 OpenStreetMap contributors, ODbL",
  "osm_pbf_path": "data/cache/pbf/austria-2026-09-11-batch-at-run4-260912.osm.pbf",
  "osm_snapshot": "",
  "run_id": "at-run4-260912",
  "elevation_provider": "BEV ALS DTM 1 m",
  "elevation_licence": "Creative Commons Attribution 4.0 (CC BY 4.0) \u2014 \u00a9 BEV / L\u00e4nder, data.gv.at",
  "elevation_dataset": "ALS DTM H\u00f6henraster 1 m (Bundesamt f\u00fcr Eich- und Vermessungswesen with the L\u00e4nder), EPSG:3035",
  "elevation_tile_ids": [
    "E4725-N2629",
    "E4725-N2630"
  ],
  "elevation_blocks": [
    "N2600000E4700000@2022-09-15"
  ],
  "climb_origin": "discovered",
  "license": "ODbL-1.0",
  "license_url": "https://howsteep.org/licensing"
}
